Technical Data
Technical specifications
Model parameters for product comparison and engineering review.
Technical Specifications
| Product model | RTX1012 |
|---|
| Product category | RFID antenna |
|---|
| Frequency range | 840 MHz-960 MHz |
|---|
| Polarization | circular polarization |
|---|
| Gain | ＞12 dBi |
|---|
| H-plane HPBW | 40 degrees |
|---|
| E-plane HPBW | 40 degrees |
|---|
| Impedance | 50 Ω |
|---|
| VSWR | ≤1.3 |
|---|
| Connector type | N-Female |
|---|
| Connector position | bottom exit |
|---|
| Dimensions | 445 mm x 445 mm x 40 mm |
|---|
| Weight | 2200 g (excluding bracket) |
|---|
| Material | engineering plastic ABS + aluminum profile |
|---|
| Housing color | White |
|---|
| Installation | pole mounting (maximum pole diameter 80 mm) |
|---|
| Operating temperature | -20 C to + 55 C |
|---|
| Ingress protection | IP65 |
|---|
