Product Parameters
| Product model | RU6530 |
|---|---|
| Product name | UHF Phased-Array Ceiling Reader |
| Working frequency | 840-960 MHz |
| Supported standards | ISO 18000-6C / EPC Gen2 |
| Reading speed | > 500 reads per second |
| Card reading quantity | <= 600 tags / 3 seconds |
| Reading / writing distance | 0-20 m, depending on tag, antenna size, and environment |
| Antenna | Built-in circularly polarized antenna |
| RF power | 33 dBm +/- 1 dB adjustable |
| Communication interface | Ethernet x1, serial port x1, optional Wi-Fi, 10M/100M adaptive |
| Working mode | Fixed-frequency / frequency-hopping optional |
| Anti-collision processing | Supported |
